Typical Applications

    Copy Paper
    Stationery
    Signatures
    Resume Paper
    Envelopes
    And many more…

Specifications

    Minimum product size: 25mm(W) x 38mm(L) [1" x 1.5"]
    Maximum product size: 300mm(W) x 400mm(L) [12" x 16"]
    Minimum product thickness: 0.05mm [0.002"]
    Maximum product thickness: 27mm [1"]
    Maximum belt speed: 211,000 mm/min [8300 in/min]
    Operating temperature: 10-35 Degrees C [50-95 Degrees F]
    Power requirements: 110 (230) volts 50-60 HZ max 6 amps
    Total unit weight: 32 kg [70 lbs]
    Product magazine: 380mm [15"]
    Feeder discharge: Five standard lengths

Standard Features

    Portable unit: Self-contained unit with only one electrical enclosure
    Computer controlled: Computer control provides thousands of control calculations per second for precise start, stop, watch dog and multiple product detection
    Easy interface: Standard signals available for easy interface with existing computer, PLC or other host machinery
    Production log: Automatically stores your production history in the feeder’s computer with production count, and fault logging with time, date and type of fault
    Intuitive user interface: Custom 22-key sealed membrane key pad with 2 x 40 character LCD display
    User-friendly changeover: Easy and accurate changeover with twist lock handles
    Ruggedly built: Hardened stainless steel shafts and sealed bearings for maximum life and 24-hour a day operation
    Quick belt replacement: Three piece shaft assemblies for quick maintenance
    Three-color signal light: Green = ready, Yellow = low product, Red = fault
    Pre-select counter: Standard pre-select product count (1-999 per cycle)
    Optically isolated signals: All interface signals isolated for accuracy
    Built for harsh environments: Stainless steel shafts, sealed bearings, surface-treated aluminum construction and sealed cast aluminum enclosures to protect internal parts
    One year warranty: One year warranty on parts and labor
    Software Lockout Function Option: Allows user to lock out some or all feeder functions for simplicity for the operator.
    Encoder Speed Match Option: Allows for an input from an encoder connected directly to the feeder to monitor the speed of the host machine. The feeder will monitor the speed of the host machine and adjust its timing accordingly.
