    High performance single sheet feeder up to 50,000 sheets per hour
    Extensive equipment up to the counting feeder with drop table and Non Stop for pile reloading without interruption off process
    High loading capacity with sheet separation of the top of the pile
    Safe sheet separation with separation head and vacuum wheel
    Material (Paper, Film etc.) from 60g/m² up to 200g/m²
    Range of formats from DIN A6 up to DIN A3

Standard Equipment

    In-feed height EH=1000mm
    Mobil undercarriage
    Pile carrier for 600mm pile 1kN load
    Vacuum wheel ∅100x45mm
    Separation device TK-HS with single vacuum cup
    Compressor KLT25 for pressure air and vacuum
    left and right side blowers at the front plate
    Conveyor with transport- and top belts
    Double sheet detector (US-DSC)
    Integrated drive via inverter
    Counter VZG
    Line 230/400V 50Hz, L1, L2, L3, N, PE

Product Options

    Second pile elevator to reload without interrupt (NON STOP)
    Preloading cart
    Separation head TK906 with special valve for very stiff material
    Catch tray to transfer single sheets (ct)
    Collating bin to transfer counted stacks (dt = drop table)
    Register table SAT50
    Register table SAT50 with discharge shaft
    Remote control EBP
    Line 220±10% 50/60Hz, L1, L2, L3, PE
